The old Shacman M3000 dump truck 12 wheeler features high-efficiency power, strong load-carrying capacity and fuel efficiency for high-intensity transportation and heavy-duty transportation needs. There is no need to worry about the quality, we offer a one-year warranty service.
Engine: The old Shacman M3000 dump truck 12 wheeler is equipped with the Weichai WP12. 400E62 engine, which has excellent maximum torque performance. It can bring strong starting ability, rapid acceleration performance and stable climbing performance to the old Shacman M3000 dump truck 12 wheeler, achieving a smooth transportation experience without frequent gear shifting. The engine of the old Shacman M3000 dump truck 12 wheeler uses high horsepower, which allows running in the medium load range.
Reliability: The old Shacman M3000 dump truck 12 wheeler is equipped with Weichai engine, Fast gearbox and Hande axle to ensure the high efficiency and reliability of power output and meet the needs of complex transportation conditions.
Old Shacman M3000 Dump Truck 12 Wheeler for Sale from China
Old Shacman M3000 Dump Truck 12 Wheeler for Sale from China
Old Shacman M3000 Dump Truck 12 Wheeler for Sale from China
Old Shacman M3000 Dump Truck 12 Wheeler for Sale from China
Old Shacman M3000 Dump Truck 12 Wheeler for Sale from China
Truck Model: SX3319
Engine Model: WP12.400E62
Drive Type: 8x4
Transmission: Fast 12JSD
Displacement: 11.6L
Fuel Tank Capacity: 300L
Max Horsepower: 400hp
Fuel Type: Diesel
Emission: Euro Ⅲ
Steering System Model: ZF, LHD
Front Axle: MAN
Rear Axle: 16T MAN
Tyre: 12.00R20
Number of Tires: 12
Wheelbase(mm): 1800+2675+1400mm
Container Form: Self-unloading Type
Container Type: Square Type
Cab Lift: Electric, Front lifting
Cargo Dimension(LxWxH)(mm): 5600×2350×1500
Dimension(LxWxH)(mm): 8700x2550x3500
Curb Weight: 15.5 Ton
Rated Load: 15.37 Ton
Tonnage Class: Heavy Truck
Carrying capacity: The body of the old Shacman M3000 dump truck 12 wheeler is made of high-strength steel. The combination of a rigid skeleton cushioning structure and an optimized chassis system improves the load-bearing performance and durability of the old Shacman M3000 dump truck 12 wheeler. The old Shacman M3000 dump truck 12 wheeler adopts a reinforced rim and driveshaft configuration to enhance the vehicle's super load-carrying capacity and adapt to diverse transportation needs.
Cargo compartment: The cargo compartment of the old Shacman M3000 dump truck 12 wheeler is stamped and formed with high-strength steel at one time, which improves the overall durability and reliability and adapts to harsh transportation environments. The cargo compartment size of the old Shacman M3000 dump truck 12 wheeler is 5600x2350x1500mm, with a large cargo compartment volume and strong loading capacity.
Cab: The interior layout of the old Shacman M3000 dump truck 12 wheeler's cab is user-friendly, equipped with adjustable seats and four-point airbag suspension. This configuration can effectively relieve the driver's fatigue after long-term driving and improve comfort.
Chassis: After the chassis system of the old Shacman M3000 dump truck 12 wheeler is optimized, the ground clearance of the water tank reaches ≥ 580mm. This greatly improves the old Shacman M3000 dump truck 12 wheeler passability, adapts to a variety of complex road conditions and maintains transportation efficiency.
Layout: The old Shacman M3000 dump truck 12 wheeler is equipped with an oversized fuel tank on the left side, which has a capacity to meet long-distance transportation needs. The old Shacman M3000 dump truck 12 wheeler has systems such as urea tank, battery pack, exhaust pipe and more arranged on the right side. The air reservoir of the old Shacman M3000 dump truck 12 wheeler is reasonably arranged on the inside and tail of the girder. This optimizes the space layout of the old Shacman M3000 dump truck 12 wheeler for easy repair and maintenance.
Stability: The old Shacman M3000 dump truck 12 wheeler is equipped with an advanced four-point hydraulic suspension system to improve the smoothness of the whole vehicle driving, especially suitable for long-distance transportation. The old Shacman M3000 dump truck 12 wheeler is equipped with a lateral damping system, which greatly reduces the inclination of the body when driving in corners and enhances the cornering stability and safety of the vehicle. At the same time, the impact on the chassis and suspension is reduced, and the repair frequency and post-maintenance costs of the old Shacman M3000 dump truck 12 wheeler are reduced.
